TP-Link Archer VR2800 - wireless router - DSL modem - 802.11a/b/g/n/ac - desktopThe Fastest VDSL Modem Router – The Archer VR2800 runs at 2167Mbps on 5GHz and 600Mbps on 2.4GHz
1GHz dual-core CPU – Broadcom 1GHz dual-core CPU with two co-processors keeps VR2800 running at peak performance
TP-Link Tether App – TP-Link Tether app helps you set up and manage your Archer VR2800 from any Android or iOS device.
terface 3 10/100/1000Mbps RJ45 LAN Ports,
1 10/100/1000Mbps RJ45 WAN/LAN Port,
1 RJ11 Port,
2 USB 3.0
Button WPS Button,
Wi-Fi Button,
Reset Button,
LED On/Off Button,
Power On/Off Button
External Power Supply 12V/3.3A
IEEE Standards IEEE 802.3, IEEE 802.3u, 802.3ab
VDSL2 Standards TU G.993.2, Up to 17a profile (POTS)
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP）
ADSL Standards Full-rate ANSI T1.413 Issue 2,
ITU-T G.992.1(G.DMT),
ITU-T G.992.2(G.Lite),
ITU-T G.994.1 (G.hs)
ADSL2 Standards ITU-T G.992.3 (G.DMT.bis)
ADSL2+ Standards ITU-T G.992.5
Dimensions ( W x D x H ) 10.4 × 7.8 × 1.5 in
(263.8 × 197.8 × 37.3 mm)
Antenna Type 4 external detachable dual band antennas (RP-SMA)
WIRELESS FEATURES
Wireless Standards IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency 2.4GHz and 5GHz (Supports DFS)
Transmit Power <20dBm (2.4GHz),
<23dBm (5GHz Band1 & Band2),
<30dBm (5GHz Band3)
Wireless Security 64/128-bit WEP,
WPA/WPA2,
WPA-PSK/WPA-PSK2 encryptions
SOFTWARE FEATURES
Quality of Service ATM QoS,
Traffic Control (IP QoS)
Security NAT Firewall, SPI Firewall, Access Control, Service Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death, IP and MAC Address Binding
Management Web Based Configuration (HTTP / HTTPS ), Remote management,
Command Line Interface, SSL for TR-069, SNMP v1/2c, Firmware Upgrade, Diagnostic Tools, Free Online Firmware Update
Port Forwarding Virtual Server, Port Triggering, DMZ, ALG, UPnP
VPN Pass-Through OpenVPN, PPTP VPN, IPSec VPN
Protocols Support IPv4 and IPv6
ATM/PPP Protocols ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516),
IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs
Advanced Features Parental Controls, Network Address Translation(NAT), Port Mapping
(Grouping),
Static Routing, RIP v1/v2 (optional), DNS Relay, DDNS, IGMP V1/V2/V3
USB Sharing Support Samba (Storage) / FTP Server / Media Server / Printer Server, 3G/4G Modem / SFTP Server / Web Storage
Others:Certification CE, RCM, RoHS
Package Contents AC2800 Wireless MU-MIMO VDSL/ADSL Modem Router Archer VR2800
External Splitter
RJ11 DSL Cable
RJ45 Ethernet Cable
Power Adapter
Quick Installation Guide
System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10,
Mac OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Subscription with an internet service provider (for internet access)
Environment Operating Temperature: 0℃~40℃(32℉~104℉)
Storage Temperature: -40℃~70℃(-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
